The monitoring cabinet is a kind of cabinet, which is used to combine installation panels, plug-ins, sub-boxes, electronic components, devices and mechanical parts and components to form an integral installation box.

The monitoring cabinet is composed of a frame and a cover (door), generally in the shape of a cuboid, and is placed on the ground. It provides suitable environment and safety protection for the normal operation of electronic equipment. This is the first level assembly after the system level. A cabinet that does not have an enclosed structure is called a rack.

Most of the monitoring cabinets used in the early days were made of castings or angle steel connected by screws, rivets or welded to form a cabinet frame, and then a cover plate (door) made of thin steel plate. This kind of cabinet is bulky, bulky, and simple in appearance, and has been eliminated. With the use of transistors and integrated circuits and the ultra-miniaturization of various components and devices, the structure of the cabinet is also developing in the direction of miniaturization and building blocks. The monitoring cabinet has been developed from the whole panel structure in the past to the plug-in box and plug-in structure with a certain size series. The assembly and arrangement of sub-boxes and plug-ins are divided into two types: horizontal arrangement and vertical arrangement. The monitoring cabinet materials generally use thin steel plates, steel profiles with various cross-sectional shapes, aluminum profiles and various engineering plastics. In addition to welding and screw connection, the frame of the monitoring cabinet also adopts the bonding process.

Optional accessories:

Special fixed trays, special sliding trays, power brackets, ground casters, anchor nails, cable management rings, horizontal cable management racks, vertical cable management racks, L brackets, extension beams, etc. The main frame, front and rear doors, left and right side doors can be quickly disassembled. Fixed tray: It is used to install various equipment, with a wide range of sizes and a wide range of uses. There are 19" standard trays, non-standard fixed trays, etc. The depth of the conventionally configured fixed trays is 440mm, 480mm, 580mm, 620mm and other specifications. The load-bearing of the fixed tray is not Less than 50KG. It is suitable for the placement of internal equipment in various monitoring cabinets of ZTE.

Monitoring equipment room cabinet use:

1. Keep the computer room clean and beautiful: The cabinet can make the computer room easy to manage and beautiful.

2. Guarantee the power management in the cabinet of the monitoring equipment room: It is used to provide intelligent power consumption and energy consumption analysis and management functions in the cabinet, such as equipment status detection function, UPS, power distribution switch detection, etc.

3. Ensure the temperature and humidity management in the cabinet of the monitoring equipment room: monitor local temperature and humidity changes, and monitor and control the temperature and humidity conditions in the cabinet equipment cabin in real time.

4. Guarantee the management of smoke in the cabinet of the monitoring equipment room: the fire state detection of the cabinet is carried out. When an abnormal situation occurs in the intelligent cabinet system, the relevant alarm status can be displayed on the display interface.

5. Ensure the heat dissipation management in the cabinet of the monitoring equipment room: set a set of temperature ranges. When the temperature in the regulated power supply system exceeds this range, the cooling unit will automatically start to work.

6. Cabinet door management: The cabinet door adopts a built-in structure, and the gap between the door gaps is tight. The structure is firm and the anti-theft is strong. Door open alarm sensors are installed on each cabinet door to complement security monitoring.

The monitoring equipment room cabinet is suitable for most computer room monitoring systems, and the monitoring and management effect of the cabinet is more significant.

Features of monitoring cabinet:

1. The monitoring cabinet has good technical performance. The structure of the cabinet should be based on the electrical and mechanical performance of the equipment and the requirements of the use environment, and the necessary physical and chemical design should be carried out to ensure that the structure of the cabinet has good rigidity and strength, as well as good electromagnetic isolation, grounding, noise isolation, ventilation and heat dissipation. and other performance.

2. The monitoring cabinet should have anti-vibration, anti-shock, anti-corrosion, dust-proof, waterproof, anti-radiation and other properties, so as to ensure the stable and reliable operation of the equipment.

3. The monitoring cabinet should have good usability and safety protection facilities, which are convenient for operation, installation and maintenance, and can ensure the safety of operators. The network cabinet should be easy to manufacture, assemble, debug, and package for transportation.

4. The monitoring cabinet should meet the requirements of standardization, normalization and serialization. The cabinet is beautiful in appearance, suitable for use, and color-coordinated.

Although the monitoring cabinet function is very powerful, when making a selection, choose products made by reliable manufacturers to ensure the quality and use effect.JAVA Metal specializes in the production of self-service equipment cabinets, network cabinets, communication cabinets, power cabinets, monitoring cabinets and energy storage cabinets. The company has passed the ISO9001-2008 international quality system certification, and is a sheet metal processing manufacturer integrating R&D, production, processing and after-sales service.
